Biostar Z790 Valkyrie (LGA1700, Z790, DDR5, USB3.2 Type-C, SATA3)
Original price was: Rp3,985,000.00.Rp3,780,000.00Current price is: Rp3,780,000.00.
Biostar Z790 Valkyrie (LGA1700, Z790, DDR5, USB3.2 Type-C, SATA3)
Description
Biostar Z790 Valkyrie (LGA1700, Z790, DDR5, USB3.2 Type-C, SATA3)
| Chipset | Intel Z790 |
| CPU SUPPORT | Support for 12th/13th/14th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel® Pentium processors/ Intel® Celeron processors in the LGA1700 package * Please refer to www.biostar.com.tw for CPU support list. |
| MEMORY | Supports Dual Channel DDR5 – 7200+(OC) MT/s, Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM) Memory 4 x DDR5 DIMM Memory Slot, Max. Supports up to 256 GB Memory Support Intel® Extreme Memory Profile (XMP) memory modules * Please refer to www.biostar.com.tw for Memory support list. |
| INTEGRATED VIDEO | Supports DX12 Supports HDCP |
| STORAGE | Total supports 5 x M.2 socket and 8x SATA III (6Gb/s) ports Intel 12th/13th/14th Processors 1 x M.2 (M Key) Socket (M2M_CPU1): Supports M.2 Type 2280 SSD module Supports PCIe 5.0 x4 (128Gb/s) – NVMe SSD 1 x M.2 (M Key) Socket (M2M_CPU2): Supports M.2 Type 2280/ 22110 SSD module Supports PCIe 4.0 x4 (64Gb/s) – NVMe SSD Intel Z790 Chipset 1 x M.2 (M Key) Socket (M2M_SB1): Supports M.2 Type 2280/ 22110 SSD module Supports PCIe 4.0 x4 (64Gb/s) – NVMe SSD 1 x M.2 (M Key) Socket (M2M_SB2): Supports M.2 Type 2280 SSD module Supports PCIe 4.0 x4 (64Gb/s) – NVMe SSD 1 x M.2 (M Key) Socket (M2M_SB3): Supports M.2 Type 2242/ 2260/ 2280 SSD module Supports PCIe 3.0 x4 (32Gb/s) – NVMe/ AHCI SSD & SATA lll (6Gb/s) SSD 8 x SATA III Connector (6Gb/s): Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology * When using SATA SSD module on M.2 Socket (M2M_SB3), the SATA_8 connector will be disabled. * When using PCI-E module on M.2 Socket (M2M_CPU1), the PCI-E slot (PCIEx16_2) will be disabled. * When using PCI-E module on M.2 Socket (M2M_CPU1), the PCI-E slot (PCIEx16_1) will become x8. * Specifications vary by CPU types |
| LAN | Intel I226-V 10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability |
| AUDIO CODEC | ALC1220 7.1 Channels, High Definition Audio, Hi-Fi(front/rear) |
| USB | 2 x USB 3.2 (Gen2x2) Type-C port (1 on rear I/O and 1 via internal header) 1 x USB 3.2 (Gen2) Type-C port (1 on rear I/O) with DP 1.2 8 x USB 3.2 (Gen2) port (6 on rear I/O and 2 via internal header) 4 x USB 2.0 port (4 via internal header) |
| EXPANSION SLOT | INTEL 12th/13th/14th Processors 1 x PCIe 5.0 x16 Slot (x16 mode or x8/x8 mode) 1 x PCIe 5.0 x16 Slot (x8 mode) INTEL Z790 Chipset 1 x PCIe 4.0 x16 Slot (x4 mode) * Specifications vary by CPU types |
| REAR I/O | 2 x WIFI Antenna Port 1 x HDMI® Port (HDMI®2.1) 1 x DP Port (DP1.4) 1 x USB 3.2 (Gen2x2) Type-C Port 1 x USB 3.2 (Gen2) Type-C Port with DP 6 x USB 3.2 (Gen2) Port 1 x 2.5 Gigabit LAN port 5 x Audio Jack 1 x SPDIF_Out 1 x SMART BIOS UPDATE Button 1 x SMART BIOS USB Port |
| INTERNAL I/O | 8 x SATA III Connector (6Gb/s) 1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and IntelGEN2 CNVi 2 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 1 x USB 3.2 (Gen2) Header (each header supports 2 USB 3.2 (Gen2) ports) 1 x USB 3.2 (Gen2x2) Type C Header. 2 x 8-Pin Power Connector 1 x 24-Pin Power Connector 1 x CPU Fan Connector 1 x CPU water cooling connector (CPU_OPT) 4 x System Fan Connector 1 x Front Panel Header 1 x Front Audio Header 1 x Speaker Header 1 x Clear CMOS Header 1 x COM Port Header 1 x TPM Header 1 x Thunderbolt Header 2 x LED Header (5V) 1 x LED Header (12V) 1 x IO_LED Header 1 x SB_LED Header * M.2 (E key) Wi-Fi card is not provided |
| H/W MONITORING | CPU / System Temperature Monitoring Smart / Manual CPU Fan Control CPU/DDR Voltage Monitoring |
| DIMENSION | ATX Form Factor Dimension: 30.5cm x 24.4cm ( W x L ) |
| OS SUPPORT | Supports Windows Windows 10(64bit) / Windows 11(64bit) ※Biostar reserves the right to add or remove support for any OS with or without notice. |
| BUNDLE SOFTWARE | BullGuard |
| ACCESSORIES | 4 x SATA Cable 1 x DVD Driver 1 x User Manual 1 x Smart Connector |
