Asus PRIME H410M-E (LGA1200, H410, DDR4, USB3.2, SATA3)
Original price was: Rp1,185,000.00.Rp877,000.00Current price is: Rp877,000.00.
Asus PRIME H410M-E (LGA1200, H410, DDR4, USB3.2, SATA3)
Description
Asus PRIME H410M-E (LGA1200, H410, DDR4, USB3.2, SATA3)
Model
PRIME H410M-E
CPU
Intel® Socket 1200for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors *,Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**,**Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.,Supports Intel® 14nm CPU,* Refer to www.asus.com for CPU support list
Chipset
Intel® H410
Memori
2 x DIMM, Max. 64GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *,OptiMem,* 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).,Supports Intel® Extreme Memory Profile (XMP),Dual Channel Memory Architecture
Grafis
Integrated Graphics Processor *,1 x HDMI 1.4b,*Graphics specifications may vary between CPU types.
Slot Ekspansi
Intel® H410 Chipset,Intel® 10th Gen Processors ,2 x PCIe 3.0 x1,1 x PCIe 3.0 x16 (x16 mode)
Storage
Total supports 1 x M.2 slots and 4 x SATA 6Gb/s ports,Intel® H410 Chipset : ,1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)*1,4 x SATA 6Gb/s port(s)
LAN
Realtek® RTL8111H
Audio
Realtek ALC8877.1-Channel High Definition Audio CODEC *2,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback,- LED-illuminated design,- Audio Shielding,- Dedicated audio PCB layers,- Premium Japanese audio capacitors,Audio Feature :
Port USB
Rear USB Port ( Total 4 ),Front USB Port ( Total 6 ),2 x USB 3.2 Gen 1 port(s)(2 x Type-A),2 x USB 2.0 port(s)(2 x Type-A),2 x USB 3.2 Gen 1 port(s),4 x USB 2.0 port(s)
Software Features
ASUS Exclusive Software
Armoury Crate
AI Suite 3
– Performance And Power Saving Utility
TurboV EVO
EPU
Digi+ VRM
Fan Xpert
– EZ update
ASUS CPU-Z
AI Charger
DAEMON Tools
Norton Anti-virus software (Free Trial for 60 days)
WinRAR
UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode
Armoury Crate
AI Suite 3
– Performance And Power Saving Utility
TurboV EVO
EPU
Digi+ VRM
Fan Xpert
– EZ update
ASUS CPU-Z
AI Charger
DAEMON Tools
Norton Anti-virus software (Free Trial for 60 days)
WinRAR
UEFI BIOS
ASUS EZ DIY
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS UEFI BIOS EZ Mode
ASUS Special Features
ASUS 5X PROTECTION III
– ASUS DIGI+ VRM
– ASUS LANGuard
– ASUS Overvoltage Protection
– ASUS SafeSlot Core
– ASUS Stainless-Steel Back I/O
ASUS Q-Design
– ASUS Q-DIMM
– ASUS Q-Slot
ASUS Thermal Solution
– Aluminum heatsink design
– ASUS DIGI+ VRM
– ASUS LANGuard
– ASUS Overvoltage Protection
– ASUS SafeSlot Core
– ASUS Stainless-Steel Back I/O
ASUS Q-Design
– ASUS Q-DIMM
– ASUS Q-Slot
ASUS Thermal Solution
– Aluminum heatsink design
Port I/O Belakang
2 x USB 3.2 Gen 1 Type-A,1 x PS/2 keyboard (purple),1 x PS/2 mouse (green),1 x D-Sub,1 x HDMI,1 x LAN (RJ45) port(s),2 x USB 2.0,3 x Audio jack(s)
I/O Internal
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s),1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode),1 x Speaker connector,1 x CPU Fan connector(s),1 x Chassis Fan connector(s),4 x SATA 6Gb/s connector(s),1 x 8-pin EATX 12V Power connectors,1 x System panel connector,2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s),1 x COM port(s) connector(s),1 x S/PDIF out header(s),1 x 24-pin EATX Power connector(s),1 x Front panel audio connector(s) (AAFP),1 x Clear CMOS jumper(s)
Aksesori
User manual,1 x M.2 Anchor,I/O Shield,2 x SATA 6Gb/s cable(s),1 x Supporting DVD
BIOS
128 Mb Flash ROM, UEFI AMI BIOS
Kemampuan Manajemen
WOL by PME, PXE
Sistem Operasi
Windows® 10 64-bit
Form Factor
8.9 inch x 8.0 inch ( 22.6 cm x 20.3 cm ),mATX Form Factor
Catatan
*1 When a device in SATA mode is installed on the M.2 socket, SATA6G_2 port cannot be used.
*2 A chassis with an HD audio module in the front panel is required to support 7.1-channel audio output.
*2 A chassis with an HD audio module in the front panel is required to support 7.1-channel audio output.
