Air Cylinder SMC type CDM2B20-100Z
Original price was: Rp550,000.00.Rp500,000.00Current price is: Rp500,000.00.
Mounting : Basic (Double-side bossed)
Bore Size : 20 mm
Cylinder Stroke : 100 mm
Cushion : Air Cushion
Rod end Thread : Male rod end
Fluid : Air
Proof Pressure : 1.5 MPa
Operating Pressure : 0.05 to 1.0 MPa
Ambient and Fluid Temperature : −10°C to 60°C
Stroke Length Tolerance : +1.40 mm
Piston Speed : 50 to 750 mm/s
Description
LEBIH BIJAK DALAM BERBELANJA DAN TELITI DALAM MEMBACA.
BARANG READY SILAHKAN DIORDER.
CHAT LEBIH DULU TANYAKAN STOK DAN TYPE KE KAMI.
NOTE : Untuk ketersediaan STOCK harap ditanyakan terlebih dahulu ( Terima Kasih )
Selamat Berbelanja !!!
AIR CYLINDER SMC CDM2B20-100Z
Mounting : Basic (Double-side bossed)
Bore Size : 20 mm
Cylinder Stroke : 100 mm
Cushion : Air Cushion
Rod end Thread : Male rod end
Fluid : Air
Proof Pressure : 1.5 MPa
Operating Pressure : 0.05 to 1.0 MPa
Ambient and Fluid Temperature : −10°C to 60°C
Stroke Length Tolerance : +1.40 mm
Piston Speed : 50 to 750 mm/s
